OPERATION
OPERATION
MOVING MACHINE OFF (FORWARD, REVERSE), STOPPING
MOVING MACHINE FORWARD
WARNING
When moving the machine off, check that the area around the machine
is safe, then sound the horn before starting.
Do not allow people to get near the machine.
Clear the machine's travel path of any obstacle.
Pay a particular attention to the blind spot at the rear of the machine,
when traveling the machine in reverse.
1.
Switch 4-wheel drive switch (1) (HD325 only the machine of
4WD specifications).
Lights-off position: 2-wheel drive (rear wheel drive)
Lights-on position: 4-wheel drive (all wheel drive)
NOTICE
Switch 4-wheel drive ↔ 2-wheel drive only when the travel speed is less
than 10 km/h (6.2 MPH). Shifting at a higher speed will cause failure.
REMARK
When the engine speed is 1080 rpm or above, the front wheel
starts to drive.
2.
Check that there is no warning display on the machine monitor.
3. Check that your seat belt is fastened and that dump lever (2) is
at the FLOAT position.
4.
Depress the brake pedal fully. Check that air pressure gauge
(3) is in the green range, then set parking brake lever (4) to the
TRAVEL position to release the parking brake.
3 - 82
