MAINTENANCE
SERVICE PROCEDURE
REPLACE HYDRAULIC FILTER ELEMENT
WARNING
The parts and oil are at high temperature immediately after the engine is stopped, and may cause burns. Wait for the
temperature to go down before starting the work.
When removing the oil filler cap, turn it slowly to release the internal pressure, then remove it.
1.
Turn the cap of oil filler (F) slowly to release the internal
pressure, then remove the cap.
2.
Remove bolt (1), then remove cover (2).
3.
Take out the element, then wash the inside of the case and the
removed parts.
4.
Install the new element, then install cover (2) with bolt (1).
Run the engine at high idling, and when the oil is warmed up, if the hydraulic filter clogging monitor lamp (if equipped)
flashes, replace the element immediately.
4 - 68
