ATTACHMENTS, OPTIONS
OPERATION OF ABS AND ABS/ASR
OPERATION METHOD
ABS OPERATION
WARNING
Always stop the machine before turning on the ABS/ASR main switch (3). If it is turned on while the machine is running, the
ABS/ASR may not function normally.
1. Turn on the starting switch (1). At this time, warning lamp (2)
will light up.
2.
Turn on the ABS/ASR main switch (3). Start the truck. When
the speed rises to about 10 km/h (6.2 MPH), the warning lamp
(2) will go off.
ASR OPERATION
WARNING
Turn on the troubleshooting switch (1) only when performing troubleshooting on the machine. The ABS/ASR system will not
function while the troubleshooting switch is turned on.
1. Since the ASR and ABS are interlocked, if the ABS is turned
on, the ASR is also turned on automatically.
2. The ASR information lamp (2) lights up when the system
detects slippage of the rear wheels, and the ASR starts
functioning.
6 - 29
