OPERATION
DETAILED CONTROLS AND GAUGES
SLIDING DOOR
CAUTION
When opening or closing the sliding door, select a suitable position for your left and right hands and be extremely careful not
to get your fingers caught.
Always check that the sliding door is locked at the open or closed position.
Always stop the machine on level ground when opening or closing the door.
If the door is opened or closed on a slope, the operating effort may suddenly change, so do not open or close the door on
slopes.
Door lock
When closing the door, pull the handle back to remove lock (A) ,
then pull the door to the front.
REAR UNDERVIEW MIRROR
NOTICE
Depending on the direction that the mirror is facing, it may extend outside
the swing radius (approx.100 mm (3.9 in)).
For the way of mirror adjustment, see "Rearview Mirrors (PAGE
3-80)".
3 - 49
