MAINTENANCE
MAINTENANCE PROCEDURE
REMARK
Operate the machine after halting for more than 5 minutes to eliminate bubbles in the oil inside the tank.
12. Check for oil leakage and wipe off any spilled oil.
CHANGE OIL IN SWING MACHINERY CASE
WARNING
Parts and oil are at high temperature immediately after the engine is stopped and may cause serious burns. Wait for the oil
temperature to go down before performing this operation.
Refill capacity: 8.2 liters (2.17 US gal)
1.
Remove cover (1) under the machine and put a container
under drain valve (P) to catch the drained oil.
2. Loosen drain valve (P) under the body, drain the oil, then
tighten the drain valve again.
3.
Remove the cap of oil filler (F), then add the replacement
amount of oil through oil filler (F).
4.
Pull out dipstick (G) and wipe off oil on the dipstick with cloth.
5.
Fully insert dipstick (G) into filler pipe, then remove it.
6. The oil level should be between H and L marks on the dipstick
(G). If the oil does not reach the L mark, add oil through oil filler
port (F).
7. The oil level should be between H and L marks on the dipstick
(G). If the oil does not reach the L mark, add oil through oil filler
port (F).
4 - 59
