SPECIFICATIONS
SPECIFICATIONS
SPECIFICATIONS
Item Unit PC308USLC-3E0
Operating weight kg (lb) 32,550 (71,773)
Bucket capacity m
3
(cu.yd) 1.2 (1.6)
Name of engine - Komatsu SAA6D107E-1 diesel engine
Rated horsepower of engine kW (HP)/rpm 140 (187) /2,050
A Overall length mm (ft in) 9,545 (31' 4")
B Overall height mm (ft in) 3,230 (10' 7")
C Overall width mm (ft in) 3,590 (11' 9")
D Track shoe width mm (ft in) 850 (1' 8")
E Height of cab mm (ft in) 3,175 (10' 5")
F Radius of upper structure mm (ft in) 1,830 (7' 2")
G Overall length of track mm (ft in) 4,955 (16' 3")
H Tumbler center distance mm (ft in) 4,030 (13' 3")
Min. ground clearance mm (ft in) 498 (1' 8")
Traveling speed (Lo/Mi/Hi) km/h (MPH) 2.9/3.3/4.6 (1.8/2.1/2.9)
Swing speed rpm 9.5
5 - 2
