OPERATION
MACHINE OPERATIONS AND CONTROLS
STEERING THE MACHINE
Steering
WARNING
Before operating the travel levers, check the direction of the track frame (the position of the sprocket). If the sprocket is at the rear,
the machine moves in the reverse direction to the operation of the travel levers.
Use the travel levers to change direction.
Avoid sudden changes of direction as much as possible.
Especially when performing counter-rotation (spin turn), stop the
machine before turning.
Operate two travel levers (1) as follows.
Steering the Machine when Stopped
When turning to the left:
Push the right travel lever forward to turn to the left when traveling
forward; and pull it back to turn left when traveling in reverse.
(A): Forward left turn
(B): Reverse left turn
REMARK
When turning to the right, operate the left travel lever in the same
way.
3 - 106
