MAINTENANCE
MAINTENANCE PROCEDURE
CHECK OIL LEVEL IN DAMPER CASE, ADD OIL
WARNING
Parts and oil are at high temperature immediately after the engine is stopped and may cause serious burns. Wait for the oil
temperature to go down before performing this operation.
NOTICE
Park the machine on flat ground and stop the engine. After waiting for more than 30 minutes after stopping the engine, check the
oil level.
1.
Open the rear door at the right of the machine.
2. Remove plug (G) and check the oil level. if the oil level is near
the bottom of the plug hole, the oil amount is at a proper level.
If found short, remove plug (F) and replenish oil through plug
(F) filler port up to the bottom of plug (G) hole.
NOTICE
If excess oil is supplied, drain it to the specified amount to avoid
overheating.
3. Install plugs (G) and (F).
4.
Close the door.
4 - 60
