PC58UU-3
20-113
b
TESTING AND ADJUSTING
H
Y
D
R
A
U
L
I
C
P
R
E
S
S
U
R
E
I
N
W
O
R
K
E
Q
U
I
P
M
E
N
T
,
S
W
I
N
G
,
A
N
D
T
R
A
V
E
L
C
I
R
C
U
I
T
S
4. Measuring swing circuit and blade circuit relief
pressure
1) Remove oil pressure pickup plug (3) (10
mm, P = 1.25).
2) Install oil pressure gauge C1 (39.2 MPa {400
kg/cm²}).
3) Run the engine at full throttle and relieve
the swing circuit and blade circuit and mea-
sure the oil pressure at this time.
Stop swinging securely by
using the work equipment.
Move the blade cylinder to
the stroke end.
