TROUBLESHOOTING
T-ADAPTER - BOXES AND T-ADAPTER TABLE
The part Nos. of the T-adapter boxes and T-adapters are shown in the columns and those of the wiring har-
ness checker assemblies are shown in the lines.
KIT Part No.
Part No. Type of connector No. of pins
799-601-2500 799-601-2700 799-601-2800 799-601-2900 799-601-3000 799-601-5500 799-601-6000 799-601-6500 799-601-7000 799-601-7100 799-601-7400 799-601-7500 799-601-8000 799-601-9000 799-601-9100 799-601-9200 799-601-9300
—
799-601-2600 Box for measurement Econo-21P
QQQ QQQ
799-601-3100 Box for measurement MS-37P
Q
799-601-3200 Box for measurement MS-37P Q
799-601-3300 Box for measurement Econo-24P Q
799-601-3360 Plate For MS box
799-601-3370 Plate For MS box
799-601-3380 Plate For MS box
799-601-3410 BENDIX(MS) 24P
QQ
799-601-3420 BENDIX(MS) 24P
QQ
799-601-3430 BENDIX(MS) 17P
QQ
799-601-3440 BENDIX(MS) 17P
QQ
799-601-3450 BENDIX(MS) 5P QQ
799-601-3460 BENDIX(MS) 10P QQ
799-601-3510 BENDIX(MS) 5P
QQ
799-601-3520 BENDIX(MS) 14P
QQ
799-601-3530 BENDIX(MS) 19P
QQ
799-601-2910 BENDIX(MS) 14P
QQ
799-601-3470 Case
Q
799-601-2710 MIC 5P
QQ Q Q
799-601-2720 MIC 13P QQ Q Q
799-601-2730 MIC 17P QQQQ QQ Q
799-601-2740 MIC 21P QQQQ QQ Q
799-601-2950 MIC 9P
QQQ Q
799-601-2750 ECONO 2P
QQ
799-601-2760 ECONO 3P
QQ
799-601-2770 ECONO 4P
QQ
799-601-2780 ECONO 8P
QQ
799-601-2790 ECONO 12P
QQ
799-601-2810 DLI 8P QQ
799-601-2820 DLI 12P QQ
799-601-2830 DLI 16P QQ
799-601-2840 Extension cable
QQ Q
799-601-2850 Case
Q
799-601-7010 X 1P
QQ
799-601-7020 X 2P
QQQ Q
799-601-7030 X 3P
QQQ Q
799-601-7040 X 4P
QQQ Q
799-601-7050 SWP 6P QQQ
799-601-7060 SWP 8P QQQ
799-601-7310 SWP 12P Q
799-601-7070 SWP 14P
QQ
T-ADAPTER - BOXES AND T-ADAPTER TABLE
(6)
