PC58UU-3 01-11
GENERAL
WEIGHT TABLE
k This mass list is for reference in handling or transporting these components.
Unit: kg
Machine model PC58UU-3
Serial Number 20001 – 22000 22001 – 22300
Engine assembly (without water or oil) 270 270
• Engine (without water or oil) 200 200
• Engine mount 12 12
•PTO 8.2 8.2
• Hydraulic pump 28 28
Cooling assembly 20 20
•Radiator 5 5
• Oil cooler 3.4 3.4
Revolving frame 590 590
Canopy 164 164
Operator cab 195 195
Operator seat 26 26
Fuel tank (without fuel) 7 7
Hydraulic tank (without hydraulic oil) 50 50
Control valve 35 35
Counterweight 750 750
Swing motor (with brake valve) 15 15
Swing circle 66 66
Swing machinery 35 35
Center swivel joint 18 18
Track frame assembly 940 940
• Track frame 539 539
• Idler assembly 46 x 2 46 x 2
• Recoil spring assembly 16 x 2 16 x 2
• Carrier roller 2.2 x 2 2.2 x 2
• Track roller 10 x 10 10 x 10
• Travel motor (with speed reducer) 60 x 2 60 x 2
• Sprocket 12 x 2 12 x 2
Track shoe assembly
• Road liner (400 mm) 280 x 2 280 x 2
• Rubber shoe (400 mm) 222 x 2 222 x 2
• City pad shoe (400 mm) 263 x 2 263 x 2
(7)
WEIGHT TABLE
