OPERATION OPERATION
3-57
CHECK BEFORE STARTING 3
Always carry out the items in this section before starting the engine each day.
CHECK OIL LEVEL IN ENGINE OIL PAN, ADD OIL
WARNING
The parts and oil are at high temperature immediately after the engine is stopped, and may cause serious
burns. Wait for the temperature to go down before starting the operation.
1. Open the engine side cover on the right side of the chassis.
2. Take out the dipstick (G) and wipe off the oil with cloth.
3. Insert dipstick (G) fully in the oil filler pipe, then take it out
again.
4. The oil level should be between the H and L marks on dip-
stick (G).
If the oil level is below the L mark, add oil through oil filler
(F).
5. If the oil is above the H line, open drain valve (P), drain the
excess engine oil, then check the oil level again.
6. If the oil level is correct, tighten oil filler cap (F) securely
and close the inspection window.
REMARK
When checking the oil level after the engine has been oper-
ated, wait for at least 15 minutes after stopping the engine
before checking.
If the machine is at an angle, make it horizontal before check-
ing.
