Komatsu WA320-5H Service Manual

FUEL, COOLANT AND LUBRICANTS MAINTENANCE
4-10
PROPER SELECTION OF FUEL, COOLANT AND LUBRICANTS 4
(1): Please use SAE10W30 for the oil in the hydraulic system. If Komatsu genuine oil is not available, select the oil
from the table below.
WA320-5H
LUBRICANTS, FUELS AND FILLING CAPACITIES
Lubricant and
operating
medium
Short code /
cask lettering
Quality grade
Temperature
range
Viscosity
range
Filling
capacitiy in
litres
Engine Engine oil
EO 0030A
EO 0540A
EO 10
EO 30
EO 1030A
EO 1540A
CCMC D4
or, if not available:
API CD or
API CE or
API CF -4
-30° up to 40° C
-25° up to 40° C
-20° up to 10° C
0° up to 40° C
-20° up to 40° C
- 15° up to 50° C
SAE 0W-30
SAE 5W-40
SAE 10
SAE 30
SAE 10W-30
SAE 15W-40 *)
20
(19,5 **)
Transfer case Engine oil EO 10
CCMC D4
or, if not available:
API CD or API CE or
API CF -4
-30° up to 40° C SAE 10W*)
8,0
(6,5 **)
Hydraulic
system
Hydraulic oil HYD 0530 HVLP, HVLP D -30° up to 40° C
ISO VG46 *)
(1)
155
(89**)
Axle with
standard
differential
Axle oil
AXO 80 (*2)
AXO Fuchs: TITAN
HYDRA ZF 20W-40
-30° up to 40°C
-10° up to 45° C
80W
SAE 20W-40 *)
each 24
(each 24**)
or Engine oil EO 30
CCMC D4
or, if not available:
API CD or API CE or
API CF -4
0° up to 40° C SAE 30
Axle with
limited-slip
differential (*3)
Axle oil (*4) AXO
Shell: DONAX TD 5W-30***
Esso: TORQUE FLUID56****
Mobil: MOBILFLUID 424
Fuchs: TITAN HYDRA ZF 20W-40
SAE 5W-30
SAE 20W-40 *)
Fuel tank Diesel fuel
ASTM D975 No.1
ASTM D975 No.2
DIN-EN 590
CFPP class B
CFPP class D
CFPP class F
-30° up to -10° C
-10° up to 40° C
0° up to 40° C
-10° up to 40° C
-20° up to 40° C
----- 228
Grease nippels
Multi purpose
grease on a
lithium base
MPG-A KP2N-20 -30° up to 40° C NLGI-No. 2 ---
Grease box of
central lubrica-
tion unit
Multi purpose
grease on a
lithium base
MPG-A KP2N-20 -30° up to 40° C NLGI-No. 2 ---
Cooling system
Water and
coolant
SP-C Add antifreeze with corrosion resistor 20
Air conditioner Coolant NRS R134a (CFC-free) 860 g
* Work filling
** Top-up quantity
*** North American manufacted DONAX TD 20W-40 must not be used.
**** North American manufacted TORQUE FLUID 56 must not be used.
Supplier Engine oil (The 15W40 oil marked * is CE.)
BP Vanellus C3 (15W40)
EXXON(ESSO)
Essolube D3, *Essolube XD-3, *Essolube XD-3 Extra, *Essolube heavy duty,
Exxon heavy duty
GULF Super duty motor oil, *Super duty plus
MOBIL Delvac 1300, *Delvac super (10W-30, 15W-40)
SHELL Rimura X, Rotella T 10W30
