Operation 3.2 Explanation of components
WA470-6H – VEAM946100 3-41
(*) E.C.S.S.: Electrically Controlled Suspension System
(1) Starting switch
(2) Power mode selector switch
(3) Transmission shift mode selector switch
(4) Transmission cut-off switch
(5) Transmission cut-off set switch
(6) Lamp switch
(6) Turn signal lever
(6) Dimmer switch
(7) Horn button
(8) Hazard lamp switch
(9) Parking brake switch
(10) Front working lamp switch
(11) Rear working lamp switch
(12) Monitor panel mode selector switch 1
(13) Monitor panel mode selector switch 2
(14) Kickdown switch
(15) Hold switch
(16) Front wiper switch
(17) Rear wiper switch
(18) Cigarette lighter
(19) Room lamp switch
(20) Rear heated wire glass switch
(21) E.C.S.S. switch (*) (Option)
(22) Emergency steering switch
(23) Cooling fan reverse rotation switch
(24) Directional selector switch
(25) Directional selector actuation switch
(26) Torque converter ock up switch (Option)
