5.1 Technical data Technical Data
5-2 WA470-6H – VEAM946100
5.1 Technical data
Item Unit
WA470-6H standard specification machine
(when using POWER mode)
Operating weight (including 1 operator: 80 kg)
(with bolt on cutting edge).
kg 22,910
Normal load kg 6,970
Bucket capacity Heaped m³ 4.1 (5.4)
Engine model - KOMATSU SAA6D125E-5 diesen engine
Flywheel horsepower
kW (HP)/
rpm
203 (272)/2,000
A Overall length mm 8,970
B Overall height mm 3,470
C Max. dimension when shaking bucket mm 5,975
D Overall width mm 2,975
E Min. ground clearance mm 505
F Bucket width mm 2,990
G Clearance
Cutting edge
[BOC tip]
mm 3,085 [3,010]
H Reach
Cutting edge
[BOC tip]
mm 1,280 [1,315]
I Dump angle degrees 45,5
Min. turning radius
Cutting edge mm 6,925
Outside tire mm 6,265
Permissible towing load kg (N) 191 (19,500)
Travel speed
Forward
1st km/h 6.3
2nd km/h 12.1
3rd km/h 21.7
4th km/h 34.9
Reverse
1st km/h 6.7
2nd km/h 12.8
3rd km/h 23.0
4th km/h 36.0
Hydraulic pressure
Lift circuit
Tilt circuit
bar 350
