TROUBLESHOOTING

6-17

CHECKING THE SERVICE BRAKE

• Danger of accidents!

Always put on the safety belt.

Drive the machine on a flat, dry and solid road at a speed of 20

km/h and apply brakes. For this purpose, release the accelerator

pedal and quickly step on the brake pedal. The braking distance

must not exceed 5m.

☞

• All repairs on the brake system must be performed by a

garage which is authorised by Komatsu.
