MAINTENANCE EVERY 1000 OPERATING HOURS

7-62

CHECKING/ADJUSTING THE INJECTION NOZZLES, NOZZLE PRESSURE/

FUEL-JET PATTERN

☞

• Have the nozzle pressure of the injection nozzles and the

fuel-jet pattern checked and adjusted at your local Komat-

su dealer.

CHECKING THE ACCUMULATOR GAS PRESSURE

Each time you perform the operations described in the sections

Every 1000 Service Hours or when replacing safety-relevant

parts in the pre-defined intervals, you should ask your Komatsu

dealer to check the accumulator gas pressure.

☞

• In countries with a hot climate, the responsible Komatsu

dealer must check the gas-pressure of the pressure reser-

voir already every 650 hours.
