5-24 bizhub 658e/558e/458e/368e/308e
When a message appears to replace consumables or carry out cleaning
5
5.5
Finisher FS-536 SD
- The figure shows the Finisher FS-536 SD equipped with Punch Kit PK-520 and Relay Unit RU-513.
- Do not remove staples that remain in the machine. Otherwise, the stapling function will activate but no
sheets will be stapled.
NOTICE
When moving the Saddle Stitcher, be sure to only hold the handle. Otherwise, your hand or finger may get
caught in the machine.
Be sure to replace the Saddle Staple Cartridge after the relevant message has appeared. If a Saddle Staple
Cartridge is removed before the relevant message appears, it may result in a failure.
Saddle Stitcher
Saddle Staple Cartridge 1
Saddle Staple
Cartridge 2
To Next Page
