Konica Minolta SKR 3000 User Manual

128
7.1 Specications
7.1.8 AeroDR Generator Interface Unit2
Item Description
Product name (model name) AeroDR Generator Interface Unit2 (AeroDR Generator Interface Unit2)
Power requirements
When the AC adapter is used:
Supplied from the dedicated AC adapter.
When the AeroDR Interface Unit is used:
Supplied from the AeroDR Interface Unit via the Ethernet cable.
When the Power Supply Unit is used:
Supplied from the Power Supply Unit via the Ethernet cable.
Power supply when using the dedi-
cated AC adapter
AC 100 V-240 V ±10 %, single phase, 50/60 Hz
Power consumption when using
the dedicated AC adapter
72 VA (100 V-240 V)
External dimensions
210(W)×150(D)×50(H) mm
210 mm
150 mm
50 mm
Weight 0.9 kg
The dedicated AC adapter
specications
Product Name : AC Power Adapter (Model Number. Power-Win Technology Corp.
PW-M015A-1Y050KZ)
Dimensions : 78×50×35 mm (excluding wall mount & cable)
Weight : 130 g
INPUT : AC 100 V-240 V 0.6 A-0.3 A 50 Hz-60 Hz
OUTPUT : DC 5 V 3 A
Safety : IEC60601-1 Class II
7.1.9 Generator Interface Unit 3
Item Description
Product name (model name) Generator Interface Unit 3 (G-51)
Power requirements
When the AC adapter is used:
Supplied from the dedicated AC adapter.
When the Power Supply Unit is used:
Supplied from the Power Supply Unit via the Ethernet cable.
Power supply when using the dedi-
cated AC adapter
AC 100 V-240 V ±10 %, single phase, 50/60 Hz
Power consumption when using
the dedicated AC adapter
72 VA (100 V-240 V)
External dimensions
195(W)×150(D)×43(H) mm
195 mm
150 mm
43 mm
Weight 1.0 kg
The dedicated AC adapter
specications
Product Name : AC Power Adapter (Model Number: Power-Win Technology Corp.
PW-M015A-1Y050KZ)
Dimensions : 78×50×35 mm (excluding wall mount & cable)
Weight : 180 g
INPUT : AC 100 V-240 V 0.6 A-0.3 A 50 Hz-60 Hz
OUTPUT : DC 5 V 3 A
Safety : IEC60601-1 Class II
