Information on This Document 1
How to use this document 1.5
EasyCut F 320 M
Original Operating Instructions 150000808_01_en 7
1.5.2 Information on direction
Directional information in this document, such as front, rear, right and left, applies in the
direction of travel of the machine.
1.5.3 Term “machine”
Throughout the rest of this document, the “front mounted mower” will also be referred to as the
“machine”.
1.5.4 Figures
The figures in this document do not always represent the exact machine type. The information
that refers to the figure always corresponds to the machine type of this document.
1.5.5 Scope of the document
In addition to standard equipment, accessories kits and versions of the machine are described
in this document. Your machine may deviate from this document.
1.5.6 Means of representation
Icons in the text
The following means of representation (icons) are used to present the text more clearly:
This arrow characterizes an action step. Several arrows in a row identify a sequence of
actions to be performed step by step.
This icon identifies a prerequisite that has to be fulfilled to perform an action step or a
sequence of actions.
This arrow marks the intermediate result of an action step.
This arrow identifies the result of an action step or sequence of actions.
This bullet point identifies an enumeration. If the bullet point is intended, it identifies the
second level of the enumeration.
Icons in figures
The following icons can be used in illustrations:
Icon Explanation Icon Explanation
Reference sign for part Position of a part (e.g. move from
position I to position II)
Dimensions (e. g. also B = width,
H = height, L = length)
Magnification of display detail
Left-hand side of the machine Right-hand side of the machine
side
Direction of travel Moving direction
Reference line for visible material Reference line for covered mater-
ial
Centre line Cable routes
