Information on This Document 1
How to use this document 1.5
EasyCut F 320 M
Original Operating Instructions 150000808_01_en 9
Warnings of property damage/environmental damage
Warnings of property/environmental damage are separated from the remaining text and marked
with "Notice".
Example:
NOTICE
Gearbox damage due to low oil level
The gearboxes could be damaged when the oil level is too low.
Check gear oil level at regular intervals and top up oil, if necessary.
Check gear oil level approx. 3 to 4 hours after the machine has been switched off. Check
oil level only when machine is in horizontal position.
Notes with information and recommendations
Additional information and recommendations for trouble-free and productive operation of the
machine are separated from the remaining text and marked with “Information”.
Example:
INFORMATION
Each safety label is provided with an order number and can be ordered directly from the
manufacturer or from the authorized specialist dealer.
1.5.7 Conversion table
The following table can be used to convert metric units into US units.
Size SI units (metric) Factor Inch-pound units
Unit name Abbrevi-
ation
Unit name Abbrevi-
ation
Area Hectare ha 2.47105 Acre acres
Volume flow Litres per minute L/min 0.2642 US gallons per
minute
gpm
Cubic metres
per hour
m³/h 4.4029
Force Newton N 0.2248 Pound force lbf
Length Millimetre mm 0.03937 Inch in.
Metre m 3.2808 Foot ft.
Power Kilowatt kW 1.3410 Horsepower hp
Pressure Kilopascal kPa 0.1450 Pounds per
square inch
psi
Megapascal MPa 145.0377
bar (non-SI) bar 14.5038
Torque Newtonmeter Nm 0.7376 pound-foot or
foot-pound
ft∙lbf
8.8507 pound-inch or
inch-pound
in∙lbf
Temperature Degrees Celsius °C °Cx1.8+32 Degrees
Fahrenheit
°F
