6 Start-up
Pos: 16.2 /Übersc hriften/Übersc hriften 2/A-E/An bau an den Trakt or @ 0\mod_ 119971784519 4_78.docx @ 3 4039 @ 2 @ 1
6.1 Mounting onto the Tractor
Pos: 16.3 /BA/Sich erheit/Gefahr enhinweise/M ähwerke/Gefahr - Un beabsichtigt es Abkuppeln a ngebaute @ 9\ mod_12205379 42289_78.doc x @ 126969 @ @ 1
Danger! - Inadvertent uncoupling of the machine during road travel or work.
Effect: Danger to life, serious injuries or serious damage to the machine.
• Use extreme caution when attaching or detaching devices to or from the tractor! The
accident prevention regulations must be complied with absolutely.
• The lower suspension arms on the tractor must be fixed in position
with the retaining chains or bars to prevent the machine from swivelling out during
transport or work. If the lower suspension arms (1) are equipped with catch hooks, the
following items must be taken into consideration:
Especially in the headland position, high forces develop in the lower suspension arm bolts (3)
that act upwards in the left-hand hook.
For this reason, the catch hooks must be in a flawless condition.
Additionally, the catch hooks must be secured in the provided locking hole (4) against
unwanted opening after the machine has been connected to the tractor.
Pos: 16.4 /BA/Sich erheit/Gefahr enhinweise/M ähwerke/Warnung - Achslasten Beei nträchtigung derL enkfähigkeit @ 9 \mod_122086 6555985_78. docx@ 128119 @ 2 @ 1
Warning - Impairment of the steerability of the tractor.
Effect: Damage to the tractor or the machine.
The attachment of implements at the front and rear must not cause exceedance of the max.
permissible weight, of the permissible axle loads and of the carrying capacities of the tractor
tyres. Even with a fitted rear-mounted accessory unit, the front axle must always be loaded with
a minimum 20% service weight of the tractor.
Make sure that these prerequisites are met prior to driving.
Pos: 16.5 /BA/In betriebnahme/„Quic k-Hitch Rah men“ @ 46\mod_1 281442692281 _78.docx @ 444458 @ @ 1
CAUTION!
Only assemble the machine directly to the three-point suspension of the tractor.
It is not permitted to assemble the machine to a "Quick-Hitch frame“ (U-frame coupler).
