Krone EasyCut R 320 User Manual

Operation
34
Pos: 20.1 /Übersc hriften/Übersc hriften 1/A-E/Be dienung @ 0\ mod_1199789 505403_78.docx @ 34825 @ @ 1
8 Operation
Pos: 20.2 /Übersc hriften/Übersc hriften 2/U-Z/Vo nTr ansport in Ar beitsstellung @ 2\mod_120246 6185276_78.doc x@ 59662 @ 22 @ 1
8.1 From transport into working position
Pos: 20.3 /BA/Sich erheit/Gefahr enhinweise/M ähwerke/Gefahr - A bsenken des Mä hwerks in Arbeitsstellung EC 280/320 @ 9\mod_ 12208792447 98_78.docx @ 128 439 @ @ 1
Danger! - Lowering the mowing unit into the working position
Effect: Danger to life, injuries or damage to the machine.
• Lower the mowing unit only when you are absolutely sure that neither persons, animals
nor objects are in the swivel range of the mowing unit.
• Switch on the PTO only when the mowing unit is resting on the ground.
Pos: 20.4 /BA/Sich erheit/Gefahr enhinweise/M ähwerke/Gefahr - V erriegelung prü fen EC 280/3 20 @ 9\mod_122 0879526173_ 78.docx @ 1 28463 @ 2 @ 1
Danger! - Check whether the locking mechanism (1) is folded down completely.
Effect: Danger to life, serious injuries or serious damage to the machine.
The folded-down locking mechanism secures the mowing unit against inadvertent lifting while
the machine is running.
Pos: 20.5 /BA/Bedi enung /EasyC ut/Von Trans port in Arbeitsst ellung Bild EC 3 20 - 1 @ 58\mod_1 29666184520 7_78.docx @ 553 135 @ @ 1
Fig. 13
Pos: 20.6 /BA/Bedi enung /EasyC ut/Von Trans port in Arbeitsst ellung Text EC R 280/320 @ 90\m od_1323770479 607_78.doc x@ 773458 @ @ 1
• To lower the mowing unit, pull up the lock (1) from the tractor using the actuating rope (2)
• Activate the double action control valve on the tractor to slowly lower the mowing unit
Pos: 20.7 /BA/---- ------- ----Seitenumbruch----- ----------- @ 0\mo d_11961753112 26_0.docx @ 41 65 @ @ 1
