Operation
37
Pos: 20.18 /Übersc hriften/Überschrif ten 2/A-E/A bstellstütze in Tra nsportstellu ng schwenken @ 10\mod_1221637 347634_78.doc x @ 135539 @ 1 @ 1
8.3 Swivelling parking support into transport position
Pos: 20.19 /BA/Be dienung /Eas yCut/Abstellstütze /Achtung Abstellst ütze eingekl appt EC 280/32 0CV- Q @ 10\mo d_122163753 2743_78.docx @ 135563 @ @ 1
Caution! - Parking support(s) not swivelled into transport position before road/transport
travel and for work!
Effect: Damage to the machine
• Make certain before road/transport travel and for work that the parking support(s) is/are
raised or folded in and secured in place with a bolt!
Pos: 20.20 /BA/Be dienung /Eas yCut/Abstellstütze /Abstellstütze angehoben Bild EC 320 - 1 @ 58\mod_ 129666028734 4_78.docx @ 5 52967 @ 1 @ 1
EC-333-0
1
2
2
1
Fig. 15
Pos: 20.21 /BA/Be dienung /Eas yCut/Abstellstütze /Abstellpositi on/Transportst ellung @ 58\mod _1296660164 314_78.doc x@ 552939@ 3 @ 1
I) Parking position II) Transport position
Pos: 20.22 /BA/Be dienung /Eas yCut/Abstellstütze /Abstellstütze angehoben @ 10\ mod_1221638 250775_78.docx @ 135670 @ 2 @ 1
Lift the parking support (2) into the working position of the disc mower and lock it in place with
the bolt (1).
Pos: 20.23 /BA/Be dienung /Eas yCut/Abstellstütze /Vier Stütz en( optional) Übersc hrift @ 58\mo d_129681672 3926_78.docx @ 5 54520 @ @ 1
8.3.1 Four supports (optional)
Pos: 20.24 /BA/Be dienung /Eas yCut/Abstellstütze /Vier Stütz ena ngehoben Bild EC 320 Neue Ge neration @ 58\ mod_12968167 97691_78.doc x @ 554548 @ @ 1
1
2
1
2
3
EC-349-0
1
3
1
Fig. 16
Pos: 20.25 /BA/Be dienung /Eas yCut/Abstellstütze /Abstellpositi on/Transportst ellung @ 58\mod _1296660164 314_78.doc x@ 552939@ @1
I) Parking position II) Transport position
Pos: 20.26 /BA/Be dienung /Eas yCut/Abstellstütze /Abstellstütze angehoben (4 St ützen) @ 58\mod _1296816859 394_78.doc x@ 5 54575 @ 22 @ 1
• Swivel the front parking support (2) into the working position of the disc mower and lock it
in place with the bolt (1).
• Lift the rear parking supports (3) into the working position of the disc mower and lock
them in place with the bolt (1)
