15 ELECTRICAL SYSTEM 134
15.5 Changing the ABS fuses
Warning
Fire hazard The electrical system can be overloaded if the wrong fuses are used.
– Use only fuses with the prescribed amperage. Never bypass or repair fuses.
Info
Two fuses for the ABS are located under the passenger seat. These fuses protect the return pump and the hydraulic unit of the
ABS. The third fuse, which protects the ABS control unit, is located in the fuse box.
Preparatory work
– Switch off the ignition by turning the ignition key to the position .
– Remove the passenger seat. ( p. 86)
K00362-10
To change the fuse of the ABS hydraulic unit:
–
Remove the protection cap and fuse
.
– Insert a new fuse.
Fuse (58011109115) ( p. 181)
– Mount the protection cap.
