15
ELECTRIC
AL
SYSTEM
141
15.9
Changing
the
headlight
bulb
Note
Damage
to
reflector
Reduced
brightness.
–
Grease
on
the
lamp
will
evaporate
due
to
the
heat
and
be
deposited
on
the
reflector.
Clean
the
lamp
and
keep
it
free
of
grease
before
mounting.
Preparatory
work
–
Switch
off
the
ignition
by
turning
the
ignition
key
to
the
position
.
–
Remove
the
headlight
mask
with
the
headlight.
(
p.
138)
V00064-10
Main
work
(Duke)
–
Unplug
connector
.
–
Remove
protection
cap
.
142
144
