7 COMBINATION INSTRUMENT 38
ABS warning lamp lights up yellow – Status or error messages relating to ABS. The ABS lamp flashes if the ABS
mode "SupMot" is enabled.
The TC lamp lights up yellow – The TC or MTC is not available. Contact an authorized KTM workshop. The TC lamp
flashes, if TC or MTC actively engage.
The idling speed indicator lamp lights up green – The transmission has shifted to idle.
The immobilizer indicator lamp lights up or flashes red – Status or error message for immobilizer/alarm system.
The oil pressure warning lamp lights up red – The oil pressure is too low.
The high beam indicator lamp lights up blue – The high beam is switched on.
The general warning lamp lights up yellow – An operating safety (warning) message was detected. This is also
shown on the display.
7.3 Speed
402647-11
Speed
is shown in kilometers per hour km/h or in miles per hour mph.
