15 ELECTRICAL SYSTEM 147
V00067-10
Main work
–
Adjust the beam distance of the headlight by turning screw
.
Guideline
For a motorcycle with rider, and with luggage and a passenger if applicable, the
light/dark boundary must be exactly on the lower mark (applied in: Checking the
headlight setting).
Info
Turn counterclockwise to increase the headlight range; turn clockwise to reduce
the headlight range.
If you have a payload, you may have to correct the headlight range.
15.14 Diagnostics connector
H00932-11
Diagnostics connector
is located under the front rider's seat.
