12 SERVICE WORK ON THE CHASSIS 87
12.7 Removing the passenger seat cover (Duke R)
V00053-10
–
Insert the ignition key in seat lock

and turn it clockwise.
– Raise the rear of the passenger seat cover, push it toward the rear, and remove it
upward.
– Remove the ignition key from the seat lock.
12.8 Mounting the passenger seat cover (Duke R)
Warning
Danger of accidents Accident risk caused by the presence of a passenger.
– If the passenger seat cover is mounted, the vehicle is not suitable for transporting a passenger. Do not ride with a passenger.
V00074-10
–
Hook catches

of the passenger seat cover onto the storage compartment, lower the
rear, and simultaneously push forward.
– Press down the passenger seat cover until it clicks into place.
– Finally, check that the passenger seat cover is correctly mounted.
