KTM 2016 690 DUKE R User Manual

22 TECHNICAL DATA 185
Rebound damping
Comfort 20 clicks
Standard 15 clicks
Sport 10 clicks
Full payload 10 clicks
Spring preload 11 mm (0.43 in)
Spring rate
Soft 70 N/mm (400 lb/in)
Medium (standard) 75 N/mm (428 lb/in)
Spring length 185 mm (7.28 in)
Gas pressure 10 bar (145 psi)
Static sag 25 mm (0.98 in)
Riding sag 60… 65 mm (2.36… 2.56 in)
Fitted length 370 mm (14.57 in)
Shock absorber fluid Shock absorber fluid (SAE 2.5) (50180751S1) ( p. 192)
22.9 Chassis tightening torques
Screw, headlight EJOT 2 Nm (1.5 lbf ft) –
Screw, side stand switch M4 2 Nm (1.5 lbf ft) Loctite
®
243™
Remaining screws, chassis M5 5 Nm (3.7 lbf ft) –
Retaining clamp, brake line M5 3 Nm (2.2 lbf ft) –
SAS valve screw on frame M5 4 Nm (3 lbf ft) –
Screw, air filter box M5 3 Nm (2.2 lbf ft) –
Screw, cable on starter motor M5 3 Nm (2.2 lbf ft) –
