11 TUNING THE CHASSIS 74
Guideline
Rebound damping
Comfort 17 clicks
Standard 12 clicks
Sport 7 clicks
Full payload 7 clicks
Info
Turn clockwise to increase damping; turn counterclockwise to reduce damping.
11.4 Compression damping of the shock absorber (Duke R)
The compression damping of the shock absorber is divided into two ranges: high-speed and low-speed.
High-speed and low-speed refer to the compression speed of the rear wheel suspension and not to the vehicle speed.
The high-speed setting, for example, has an effect when riding over an asphalt edge: the rear wheel suspension compresses quickly.
The low-speed setting, for example, has an effect when riding over long ground swells: the rear wheel suspension compresses slowly.
These two ranges can be adjusted separately, although the transition between high-speed and low-speed is gradual. Thus, changes in the
high-speed range affect the compression damping in the low-speed range and vice versa.
11.5 Adjusting the high-speed compression damping of the shock absorber (Duke R)
Caution
Danger of accidents Disassembly of pressurized parts can lead to injury.
– The shock absorber is filled with high density nitrogen. Adhere to the description provided. (Your authorized KTM workshop will
be glad to help.)
