23 TECHNICAL DATA
150
23.1 Engine
Design 1-cylinder 4-stroke engine, water-cooled
Displacement 249.91 cm³ (15.2505 cu in)
Stroke 52.3 mm (2.059 in)
Bore 78 mm (3.07 in)
Compression ratio 13.8:1
Idle speed 2,050 … 2,150 rpm
Control DOHC, four valves controlled via cam lever, drive via
timing chain
Valve diameter, intake 32.5 mm (1.28 in)
Valve diameter, exhaust 26.5 mm (1.043 in)
Valve clearance
Intake at: 20 °C (68 °F) 0.08 … 0.15 mm (0.0031 … 0.0059 in)
Exhaust at: 20 °C (68 °F) 0.12 … 0.19 mm (0.0047 … 0.0075 in)
Crankshaft bearing 2 cylinder bearings
Conrod bearing Slide bearing
Piston pin bearing Bearing bush
Pistons Forged light alloy
Piston rings 1 compression ring, 1 oil scraper ring
Engine lubrication Pressure circulation lubrication with 2 trochoidal
pumps
Primary transmission 24:73
Clutch Multidisc clutch in oil bath/hydraulically activated
Gearbox 6 gear transmission, claw shifted
Transmission ratio
First gear 13:32
Second gear 16:30
Third gear 16:24
Fourth gear 23:28
Fifth gear 23:23
Sixth gear 26:20
Alternator 12 V, 200 W
Ignition Contactless controlled fully electronic ignition with
digital ignition adjustment
Spark plug NGK LMAR9AI-10
Spark plug electrode gap 1.0 mm (0.039 in)
Cooling Water cooling, permanent circulation of coolant by
water pump
Starting aid Starter motor
