23 TECHNICAL DATA
156
Standard 15 clicks
Sport 12 clicks
Spring preload 10 mm (0.39 in)
Spring rate
Weight of rider: 65 … 75 kg (143 … 165 lb.) 60 … 66 N/mm (343 … 377 lb/in)
Weight of rider: 75 … 85 kg (165 … 187 lb.) 63 … 69 N/mm (360 … 394 lb/in)
Weight of rider: 85 … 95 kg (187 … 209 lb.) 66 … 72 N/mm (377 … 411 lb/in)
Spring length 225 mm (8.86 in)
Gas pressure 10 bar (145 psi)
Static sag 37 mm (1.46 in)
Riding sag 110 mm (4.33 in)
Fitted length 415 mm (16.34 in)
Damper oil Shock absorber fluid (SAE 2.5)
(50180751S1) ( p. 160)
23.9 Chassis tightening torques
Remaining screws, chassis EJOT PT
®
K60x25‑Z 2 Nm (1.5 lbf ft)
Screw, active carbon filter (All EU
models)
- 5 Nm (3.7 lbf ft)
Screw, air filter box cover EJOT PT
®
K60x20-Z 3 Nm (2.2 lbf ft)
Screw, intake air temperature sen-
sor
EJOT DELTA PT
®
45x12‑Z 0.7 Nm (0.52 lbf ft)
Screw, pressure regulator EJOT PT
®
K60x25‑Z 2.3 Nm (1.7 lbf ft)
Screw, seat fixing EJOT EJOFORM PT
®
K60x23/18 2.5 Nm (1.84 lbf ft)
Screw, emergency OFF switch M4 1 Nm (0.7 lbf ft)
Screw, fixed grip M4 5 Nm (3.7 lbf ft)
Loctite
®
243™
Spoke nipple, front wheel M4.5 6 Nm (4.4 lbf ft)
Spoke nipple, rear wheel M4.5 6 Nm (4.4 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, battery terminal M5 2.5 Nm (1.84 lbf ft)
Screw, light switch M5 1 Nm (0.7 lbf ft)
Screw, turn signal switch M5 1 Nm (0.7 lbf ft)
Nut, starter motor M6 4 Nm (3 lbf ft)
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Screw, ball joint of push rod on
foot brake cylinder
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, chain sliding guard M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, front brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, rear brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, throttle grip M6 5 Nm (3.7 lbf ft)
