6 CONTROLS
20
6.14 Cold start button
H02253-10
Cold start button
1
is fitted on the bottom of the throttle valve
body.
The injection system extends the injection time if the engine is
cold and the outside temperature is low. To help the engine burn
the increased amount of fuel, it must be supplied with additional
oxygen by pushing the cold start button.
After briefly opening up the throttle and then releasing the throttle
grip again, or turning the throttle grip towards the front, the cold
start button returns to its original position.
Info
Check whether the cold start button has returned to its
basic position.
Possible states
• The cold start button is activated – The cold start button is
pushed in all the way.
• The cold start button is deactivated – The cold start button is
in its basic position.
6.15 Idle speed adjusting screw
H02254-10
The idle setting of the throttle valve body has a big influence on
the vehicle's starting behavior, on stable idling, and on vehicle
response when the throttle is opened.
An engine with a correctly set idle speed is easier to start than an
engine with the idle speed set incorrectly.
The idle speed is adjusted using the idle speed adjusting
screw
1
.
Increase the idle speed by turning the idle speed adjusting screw
clockwise.
Decrease the idle speed by turning the idle speed adjusting screw
counterclockwise.
