6 CONTROLS

6.16 Shift lever

401950-10

The shift lever

is fitted on the left side of the engine.

401950-11

The gear positions can be seen in the photograph.

The neutral or idle position is between the first and second gears.

6.17 Foot brake lever

401956-10

The foot brake lever

is attached in front of the right footrest.

The foot brake lever is used to activate the rear brake.

6.18 Side stand

401943-10

The side stand

is attached to the left side of the vehicle.
