OPERATING THE ENGINE16
ENGLISH
C Check Easy Checker(TM) Lamps;
When the key is turned "ON", lamps (2) (3) (4) (5) (6) only
should come on. If trouble should occur at any location
while the engine is running, the warning lamp
corresponding to that location come on.
A Daily checks with the Easy Checker (TM) only, are not
sufficient. Never fail to contact daily checks carefully
by referring to Daily Check section.
(See "DAILY CHECK" in "PERIODIC SERVICE"
section.)
3. Sit on the operator's seat and adjust the
seat position.
(1) Seat
(2) Position adjust lever
(A) "PULL UP"
4. Set the throttle lever 1/2 way forward.
(1) Throttle lever : "INCREASE"
: "DECREASE"
5. Insert the key into the key switch and
turn it "ON".
(1) Turn signal / Hazard light indicator
(2) Preheat
(3) Electric charge
(4) Engine oil pressure
(5) Coolant temperature indicator
(6) Low fuel indicator
(7) High beam indicator
(8) Position light indicator
(9) Key switch
To Next Page
