27OPERATING THE MACHINE
ENGLISH
BHourmeter / Tachometer
The hourmeter indicates in six digits the hours the
machine has been used; the last digit indicates 1/10 of an
hour.
When the key is turned "ON", the tachometer should
indicate 4000 engine revolutions per minute (rpm) for just
a moment.
When the key switch is "ON" and the engine is "ON", the
tachometer indicates the engine revolution per minute.
PARKING
BParking
To avoid serious injury:
A Always set the parking brake, stop the engine
and remove the key before leaving the machine
seat.
1. When parking, be sure to set the parking brake.
To set the parking brake;
(1) Depress the brake pedal.
(2) Latch the brake pedal with the parking brake lock
pedal.
2. Before getting off the machine, disengage the PTO,
lower all implements to the ground, place all control
levers in their "NEUTRAL" positions, set the parking
brake, stop the engine and remove the key.
3. If it is necessary to park on an incline, be sure to chock
the wheels to prevent accidental rolling of the
machine.
(1) Hourmeter
(2) Tachometer
(1) Brake pedal (A) "DEPRESS"
(2) Parking brake lock pedal (B) "PUSH DOWN WHILE
DEPRESSING (1)"
To Next Page
