12. COOLING SYSTEM
12-10
GRAND DINK 125/150
Remove the four bolts and the water pump
cover, gasket and 2 dowel pins.
Remove the water pump impeller.
Inspect the mechanical (water) seal and seal
washer for wear or damage.
Impeller (Left Hand Threads)
Mechanical Seal
Seal Washer (Porcelain)
Water Pump Cover
Bolts
The impeller has left hand threads.
＊
The mechanical seal and seal washer
must be replace as a set.
＊
Impeller

KYMCO GRAND DINK 125 Specifications

General

Displacement	124.6 cc
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Seat Height	780 mm
Starting System	Electric
Cooling System	Liquid-cooled
