2. EXHAUST MUFFLER/FRAME COVERS
2-6
GRAND DINK 125/150
FRONT COVER REMOVAL
First remove the front upper cover.
Remove the two bolts attaching the front
cover.
Remove the six screws on the back of the
front cover.
Disconnect the right/left turn signal light wire
connectors.
Remove the front cover
The installation sequence is the reverse of
removal.
Remove the six screws on the front lower
cover.
Remove the front lower cover.
BACK COVER REMOVAL
Remove the front cover.
Remove the key moldings.
Remove the fuel cap moldings.
Remove the back cover bolt.
Remove the back cover.
Bolts
Key Moldings
Screws
Fuel Cap Moldings
Screws
Bolts

KYMCO GRAND DINK 125 Specifications

General

Displacement	124.6 cc
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Seat Height	780 mm
Starting System	Electric
Cooling System	Liquid-cooled
