14.STEERING HANDLEBAR/FRONT WHEEL/FRONT
BRAKE/FRONT SHOCK ABSORBER/FRONT FORK
14-2
GRAND DINK 125/150
SERVICE INFORMATION
GENERAL INSTRUCTIONS
• Remove the motorcycle frame covers before removing the front wheel, steering handlebar, front
shock absorber and front fork. Jack the motorcycle front wheel off the ground and be careful to
prevent the motorcycle from falling down.
• During servicing, keep oil or grease off the brake pads and brake disk.
SPECIFICATIONS
Item
Standard (mm)
Service Limit (mm)
Axle shaft runout
æ
0.2
Radial
æ
2.0
Axial
æ
2.0
Front shock absorber spring free length
240.6
233
Brake disk thickness
3.8_ 4.2
3.0
Brake disk runout
æ
0.30
Brake master cylinder I.D.
12.70_ 12.74
12.75
Brake master cylinder piston O.D.
12.65_ 12.68
12.64
Brake caliper piston O.D.
25.33_ 25.36
25.30
Brake caliper cylinder I.D.
25.40_ 25.45
25.45
TORQUE VALUES
Steering stem lock nut 78.4_ 117.6N-m
Steering top cone race 4.9_ 12.7N-m
Front shock absorber bolt 19.8_ 24.5N-m
Front axle nut 44.1_ 49N-m
Brake caliper bolt 24.5N_ 34.3N-m
SPECIAL TOOLS
Lock nut wrench
Front shock absorber compressor
Ball race remover
Driver handle
Outer driver, 37x40mm
Pilot, 12mm
Bearing remover
Bearing remover head, 12mm
Front wheel rim runout
