1. GENERAL INFORMATION
1-14
GRAND DINK 125/150
Throttle Cable
Radiator Air
Vent Tube
Rear Brake Fluid
Tube
Fuel Tank Inlet
Tube
Water Hose
Fuel Filler
Fuel Tank
Breather Tube
Throttle Cable
Front Stop
Switch
Wire Harness
Fuel Tank
Rear Stop
Switch

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KYMCO GRAND DINK 125 and is the answer not in the manual?

KYMCO GRAND DINK 125 Specifications

General IconGeneral
Displacement124.6 cc
TransmissionCVT
Front SuspensionTelescopic fork
Front BrakeDisc
Rear BrakeDrum
Seat Height780 mm
Starting SystemElectric
Cooling SystemLiquid-cooled
