5. ENGINE REMOVAL/INSTALLATION
5-4
GRAND DINK 125/150
Remove the right/left rear shock absorber
upper mount bolts.
Remove the two engine mounting bolts and
pull out the engine with the engine hanger
backward.
ENGINE HANGER REMOVAL
Remove the engine hanger bolts to remove the
engine hanger.
Inspect the engine hanger bushings and
stopper rubber for wear or damage.
Bushings
Rear Shock Absorber Upper Mount Bolts
Engine Hanger Bolt
Stopper Rubber
Bolt
Engine Hanger

KYMCO GRAND DINK 125 Specifications

General

Displacement	124.6 cc
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Seat Height	780 mm
Starting System	Electric
Cooling System	Liquid-cooled
