FUEL FILL CAP
To open the fuel fill cap:
Insert the ignition key in the ignition switch and turn it to
the " " position (the key can not remove). Rotate the
key clockwise to the " " position and open the fuel fill
cap (1).
Do not overfill the tank. There should be no fuel in the
filler neck (2).
After refueling, be sure to lock the fuel fill cap firmly.
(1)
(2)
30

KYMCO Xciting 300i Specifications

General

Cooling System	Liquid-cooled
Fuel System	Electronic Fuel Injection
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Seat Height	800 mm
Compression Ratio	10.5:1
Max Torque	23.5 Nm @ 6500 rpm
Starting System	Electric
Front Tire	120/70-15
Rear Tire	150/70-14
Wheelbase	1565 mm
Engine Type	Liquid-cooled, 4-stroke, SOHC
Rear Suspension	Dual shock
Bore x Stroke	72.7 x 72 mm
Ignition	Electric
