KYMCO Xciting 300i User Manual

STAND
Center stand (1)
Side stand (2)
This scooter is equipped with a center stand and side
stand.
To place the scooter on the center stand, place your foot
on the stand extension and then rock the scooter to the
rear and upward with the passenger hand rail with your
right hand, while steadying the handlebars with your left
hand.
An interlock switch is provided to cut off the ignition circuit
when the side stand is down.
The side stand down indicator will light when the side
stand left down and ignition switch is ON ( )
The side stand/ignition interlock switch works as follows:
If the side stand is down, the engine can not be started.
If the engine is running and the side stand is put down,
the engine will stop running.
!
!
(1)
(2)
40

KYMCO Xciting 300i Specifications

General

Cooling System	Liquid-cooled
Fuel System	Electronic Fuel Injection
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Seat Height	800 mm
Compression Ratio	10.5:1
Max Torque	23.5 Nm @ 6500 rpm
Starting System	Electric
Front Tire	120/70-15
Rear Tire	150/70-14
Wheelbase	1565 mm
Engine Type	Liquid-cooled, 4-stroke, SOHC
Rear Suspension	Dual shock
Bore x Stroke	72.7 x 72 mm
Ignition	Electric
