THROTTLE OPERATION

2 6 mm (0.08 0.24 in)

To adjust the free play:

1. Check for smooth rotation of the throttle grip from the

fully open to the fully closed position at both full

steering positions.

2. Measure the throttle grip free play at the throttle grip

flange.

The standaard free play should approximately:

1. Slide the rubber sleeve (1) back to expose the throttle

cable adjuster (2).

2. Loosen the lock nut (3), then turn the adjuster to obtain

the correct free play.

3. Tighten the lock nut and reinstall the sleeve.

－－

(1)

(3)

(2)

26mm

(0.08 0.24 in)

－
