KYMCO Xciting 300i User Manual

ADJUSTABLE BACKREST
To adjust:
(see page 34)
The seat is equipped with a backrest (1) which allows the
seat to be adjusted according to the riders preference or
physical condition.
Open the seat , Pull the locking lever (2)
left on the back and move the backrest back and forth
according to the riders preference or physical condition.
After cleaning or running in the rain, wipe off water
collected under the backrest before the scooter again.
(1)
(2)
Pull
35

KYMCO Xciting 300i Specifications

General

Cooling System	Liquid-cooled
Fuel System	Electronic Fuel Injection
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Seat Height	800 mm
Compression Ratio	10.5:1
Max Torque	23.5 Nm @ 6500 rpm
Starting System	Electric
Front Tire	120/70-15
Rear Tire	150/70-14
Wheelbase	1565 mm
Engine Type	Liquid-cooled, 4-stroke, SOHC
Rear Suspension	Dual shock
Bore x Stroke	72.7 x 72 mm
Ignition	Electric
