KYMCO Xciting 300i User Manual

FRONT SMALL BOX
To open:
To close:
Insert the ignition key (2) and turn it clockwise.
1. Holding the front small box lid (2) closed, turn the
ignition key counterclockwise.
2. Remove the key.
Open the box lid while riding can be hazardous.
Removing a hand from the handlebars can
reduce your ability to control the scooter.
Always keep both hands on the handlebars
during operation.
To open
To close
(1)
(2)
32
WARNING

KYMCO Xciting 300i Specifications

General

Cooling System	Liquid-cooled
Fuel System	Electronic Fuel Injection
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Seat Height	800 mm
Compression Ratio	10.5:1
Max Torque	23.5 Nm @ 6500 rpm
Starting System	Electric
Front Tire	120/70-15
Rear Tire	150/70-14
Wheelbase	1565 mm
Engine Type	Liquid-cooled, 4-stroke, SOHC
Rear Suspension	Dual shock
Bore x Stroke	72.7 x 72 mm
Ignition	Electric
