CENTER COMPARTMENT
(page 34)
MAXIMUM WEIGHT LIMIT: 10kg (22 lbs)
The center compartment is below the seat. Opening and
closing:
See "SEAT" .
Never exceed the maximum weight limit;
handling and stability may be severely affected.
The center compartment may become heated by
the engine. Do not store food and other articles
which are flammable or susceptible to heat
damage in this compartment.
Do not direct water under pressure against the
center compartment as water will be forced into
the compartment.
CAUTION
36

KYMCO Xciting 300i Specifications

General

Cooling System	Liquid-cooled
Fuel System	Electronic Fuel Injection
Transmission	CVT
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Disc
Seat Height	800 mm
Compression Ratio	10.5:1
Max Torque	23.5 Nm @ 6500 rpm
Starting System	Electric
Front Tire	120/70-15
Rear Tire	150/70-14
Wheelbase	1565 mm
Engine Type	Liquid-cooled, 4-stroke, SOHC
Rear Suspension	Dual shock
Bore x Stroke	72.7 x 72 mm
Ignition	Electric
