2-8

Installing and Setting up the Machine > Connecting Cables

Connecting Cables

Connecting LAN Cable

Connect the cable to the machine.

1 Connect the LAN cable to the network interface connector.

2 Connect the other end of the cable to the hub.

Power on the machine and configure the network.

IMPORTANT

If the power is on, turn the power switch off.

Power Off (page 2-10)

Network Setup (LAN Cable Connection) (page 2-17)
