Removing the SD card or micro SIM card while the GS18 is turned on
can cause loss of data. Only remove the SD card or micro SIM card
or unplug connecting cables when the GS18 is switched off.
☞
The SD card and micro SIM card are inserted into a slot inside the
battery compartment of the instrument.
1. Push the slide fastener of the battery compartment in the direction
of the arrow with the open-lock symbol.
2. Remove the cover from the battery compartment.
3. Slide the SD card and micro SIM card with the logo facing upwards
rmly into the slot until it clicks into position.
4. Insert the cover of the battery compartment into the compartment.
5. Push the slide fastener in the direction of the arrow with the close-
lock symbol.
4.4 Working with the Tilt Compensation
The pole can be held in a slanting position over the point to be measured
without checking the circular bubble on the pole.
Measurements are reliable and accurate even if the pole is not levelled as the
tilt values are calculated by an Inertial Measurement Unit. Tilt values contain
information about the 3D position of the pole.
The measurements are immune to magnetic disturbances as there is no mag-
netometer used.
Tilt compensation also works with Navigated and Code solutions. High accur-
acy positions are recommended to speed up the tilt compensation initializa-
tion.
Tilt compensation is turned off when RINEX logging is on.
When measuring a point, the pole tip must be stable on the point while the
pole should be in slight movement. Tilt compensation is indicated by an icon
and the Tilt LED and is maintained by natural pole movement, for example
while moving to the next point to be measured.
Insert a SD card and
micro SIM card step-
by-step
Description
38 Operation
